SYN20708 Dual-Core Bluetooth & IEEE 802.15.4 SoC
Product Overview
The Synaptics Veros™ SYN20708 is a dual-core system on chip (SoC) for Bluetooth® 5.4 and IEEE 802.15.4. The Matter-compliant SoC supports Bluetooth (BT) Classic, Bluetooth Low Energy (BLE), Zigbee®, and Thread protocols concurrently on both cores to allow simultaneous connections to multiple endpoints in heterogeneous network environments. The chip supports dual-antenna maximum ratio combining (MRC) and transmit beamforming (TxBF) for >2x range, have an integrated transmit/ receive (T/R) switch, and support an external T/R switch with external PAs/LNAs. The SYN20708 also integrates an Arm® Cortex®-M4 CPU running at 160 MHz and has a high-speed UART interface for connection with an external host processor.
Features
- Complies with Bluetooth Core Specification Version 5.4 with support for (future) 6.0 specifications
- Supports two 2.4 GHz band radios concurrently
- Supports Bluetooth Class 1 and Class 2 TX operation
- Supports Bluetooth Channel Sounding
- Supports BLE-LR, angle of departure (AoD) and angle of arrival (AoA)
- Supports IEEE 802.15.4 (OpenThread and ZBOSS) up to Version 2
- Supports Secure Boot
- Firmware download over UART for shared flash with a host processor; from local: dedicated serial flash over an SPI
Veros SYN20708
System Block Diagram
